Software
Make the upper computer easy to use and the user-friendly interface convenient to operate;
Modular development of basic components for lower computers, offering high decoupling with the upper computer;
Support writing in multiple formats;
Support parsing multiple data formats;
Support access to YUV and RAW cameras.

Hardware
The reinjection host is small in size and supports simultaneous reinjection of multi-channel sensor data.
Specifications
Product
TDATA-W(Walrus)
Processor
Horizon Robotics Journey? 5
NVIDIA Orin
Network interface
1000Base-T1*6
RJ45*4
Network
Ethernet
I/O
CAN/CANFD*12
GMSL2*16
Time synchronization
gPTP
MCU
E3
Power Supply
9~36V
Dimensions
452mm *403mm * 178mm
Protection
IP40
Operating Temperature
0℃~40℃
