Defect Inspection Equipment
INDUSTRY CHALLENGES
-
01Scratches, chips, dents, color variation, and other cosmetic defects make manual inspection vulnerable to missed defects.
-
02
Conventional systems can leave blind spots and struggle to achieve full-surface inspection.
-
03
High inspection accuracy can come at the expense of throughput, while slow operation and lengthy changeovers hinder high-volume production.
INDUSTRY SOLUTION
Purpose-built for smartphone cover glass, balancing defect sensitivity, inspection speed, and production flexibility.
The fully automated dual-track architecture integrates automatic loading, barcode identification, precision positioning, multi-station optical inspection, and intelligent sorting for unattended operation.
Area-scan and line-scan cameras, combined with multi-angle illumination and deep-learning vision algorithms, enable full-surface, blind-spot-free inspection.
High defect sensitivity and high throughput enable efficient, consistent quality control for high-volume production.
KEY ADVANTAGES
-
AI-Driven Inspection: Deep-learning algorithms achieve a false-positive rate of ≤5%, overall detection rate of ≥95%, and critical-defect detection rate of ≥99.9%.
-
High-Sensitivity Detection: Detects linear defects down to 0.01 mm and point defects down to 0.02 mm.
-
Full-Surface Coverage & Flexible Production: Supports 2D, 2.5D, and 3D products, fast changeover, cycle time of ≤1.8 s per part, and equipment uptime of ≥95%.
