Dimension Metrology Equipment
INDUSTRY CHALLENGES
-
01Separate systems are required to inspect dimensional, color, and other quality parameters.
-
02
Manual operation and lengthy inspection cycles limit overall efficiency.
-
03
Multiple single-function systems increase overall operating costs.
INDUSTRY SOLUTION
As 3C products become thinner, lighter, and more precisely engineered, automated, multi-parameter inspection is essential for consistent high-volume production.
TZTEK's integrated metrology system combines high-resolution CCD imaging and optical sensing for automated, high-speed inspection.
Six integrated stations measure color, gloss, 2D/3D dimensions, and other key parameters in a single process.
Conveyor-based material handling enables automatic loading, inspection, and unloading for streamlined production.
KEY ADVANTAGES
-
Measures hundreds of dimensional parameters per part with a cycle time of 2 s, enabling 100% in-line inspection.
-
Measurement accuracy down to 8 μm, meeting stringent precision manufacturing requirements.
-
Integrates multiple inspection functions into a single system, reducing operating costs.
